GAMCO BRIDGE

DECK FORMING MANUAL

Image of Bidwell Screed Pipe, manufactured by Gamco

SCREED PIPE

  • 2" Schedule 80 (2-3/8" O.D. Heavy Wall)

  • 10', 20' and 21' Standard. Custom sizes available.

  • Square tube screed rail available.

  • Plug welded nose tube for a gapless fit

Image Bidwell Style Screed Yoke manufactured by Gamco

SCREED YOKES

  • Yokes available for round and square screed rail

  • Many different bases available for differing job conditions.

Image of Bidwell Cup Style Screed Base manufactured by Gamco

BIDWELL CUP-STYLE BASE

  • Perfect base for overlays

  • Stable 'cup' design

  • Adjustable

SCREED BASE TYPE C

(BIDWELL CUP STYLE)

  • Perfect base for overlays

  • Stable 'cup' design

  • Heavy Duty and adjustable

Screed Base Type C, cup style manufactured by Gamco Inc
Screed Base Type C, cup style manufactured by Gamco Inc

SCREED BASE TYPE 1-S

  • Weld or epoxy to beam flange

  • Holes in base plate optional

  • Use with Pipe Sleeve

  • Plain or galvanized

Screed Base Type 1S manufactured by Gamco Inc
Screed Base Type 1S manufactured by Gamco Inc

SCREED BASE TYPE 2-S

  • Weld or epoxy to beam flange

  • Holes in base plate optional

  • Any height available

  • Plain or galvanized

Screed Base Type 2S manufactured by Gamco Inc.
Screed Base Type 2S manufactured by Gamco Inc.

SCREED BASE TYPE 1-PR

  • For precasting in concrete beams
  • Galvanized
  • Use with Pipe Sleeve
Screed Base Type 1 PR manufactured by Gamco Inc.
Screed Base Type 1 PR manufactured by Gamco Inc.

SCREED BASE TYPE 2-PR

  • For precasting in concrete beams
  • Galvanized
Screed Base Type 2 PR manufactured by Gamco Inc.
Screed Base Type 2 PR manufactured by Gamco Inc.

SCREED BASE - CLAMP ON STYLE

  • Clamp on to stirrup, rebar or weld stud

  • Use with pipe sleeve

  • Plain or galvanized available

Screed Base - Clamp On Style, manufactured by Gamco Inc.
Screed Base - Clamp On Style, manufactured by Gamco Inc.
Image of Screed Pipe Support Extension Tube, manufactured by Gamco

PIPE SLEEVE

  • Any length available

  • Use with Screed Base Type 1-S and 1-PR

  • Screed Yoke plugs into sleeve

Image of Barrier Wall Screed Hanging Bracket, manufactured by Gamco

BARRIER SCREED BRACKET

  • Custom made per customer specs

  • Adjustable
